A/C PUMP COMPRESSOR FOR Citroen Jumper Fiat Ducato Peugeot Boxer 2.5 2.8 Diesel

Buying a replacement part? Check the part number on your old unit against the cross-reference list in this listing for an exact match. If you cannot find an exact match, contact us before ordering with clear photos of your old unit, including its label, mounting points and electrical connections, or your full vehicle registration. For marine, forklift and machinery parts, send the engine or machine details instead.

A/C PUMP COMPRESSOR FOR Citroen Jumper Fiat Ducato Peugeot Boxer 2.5 2.8 Diesel

FITS: Citroen Jumper 2.5 2.8 Diesel HDi DT

Pulley Belt Type: Multi-Groove Serpentine

Seller Warranty: 1 Year

Refrigerant: R134a

FITS 5: Fiat 8140.43 8140.43N 8140.23 8140.23.2200

Manufacturer Part Number: TSP0155042 TSP0155149 TSP0159042 514470100 71721757, 71721758 F032240412 71721757 ACP156 ACP353 70817745 72440516, ACP78000P ACP78000S 6453G5 6453NR 98462134 514470100 6453G5

REPLACES BRANDS: Delphi Fiat HC-Cargo Iveco Lucas Mahle Peugeot PSA Sanden Valeo

FITS 4: Fiat 8140.63 8140.47 8140.47R 8140.67 8140.43S

FITS 3: Fiat Ducato 2.5 2.8 Diesel TDi JTD

FITS 2: Peugeot Boxer 2.5 2.8 Diesel HDi

FITS 1: 8140.43S 8140.43N F28TDCR 8140.43 244 ZCT F28DTCR

Reference OE/OEM Number: 6453NR 6453T0 98462134 E162007 E162212 090225013 SD7H15-7882, 7882 7908 SD7H157882 SD7H157908 699028, 699528 813808 CMP2075 WOOCMP2075

Brand: HC CARGO

Type: A/C Compressor

Manufacturer Warranty: 1 Year

Compressor Drive Type: Belt Driven

Pulley Groove Quantity: 5

Country of Origin: Netherlands

Unit information

Misc. information

• Oil type — PAG 100
• Oil capacity — 135 ml
• Refrigerant — R134a
• O-ring — w/
• Voltage — 12
• Family type — SD7H15

Physical information

• F — Dist. between holes 1 — 104.00
• F — Dist. between holes 2 — 104.00
• G1 — Dist. between mount. bracket/hole — 83.30
• G2 — Dist. between mount. bracket/hole 2 — 83.30
• L — Position — 60
• M — Position 2 — 30
• Rear Cover Type — MH
• C — Length mm — 250.50
• B3 — Bracket thickness B3 — 14.60
• L — Inlet — 1-14UNF
• M — Outlet — 1-14UNF

Pulley information

• B1 — Pulley Dist. B1 — 54.00
• B2 — Pulley Dist. B2 — 52.50
• Pulley Grooves — 5
• Pulley type — SP
• A — Pulley OD mm — 117.00

This compressor fits many engines, if your engine or part number is not listed below please message me for an instant response.

Part number Cross Reference

This compressor replaces any compressor with following part numbers.

If your part number is not listed below please message me for an instant response.

• TSP0155042 — Delphi
• TSP0155149 — Delphi
• TSP0159042 — Delphi
• 514470100 — Fiat
• 71721757 — Fiat
• 71721758 — Fiat Group
• F032240412 — HC-Cargo
• 71721757 — Iveco
• ACP156 — Lucas
• ACP353 — Lucas
• 70817745 — Mahle
• 72440516 — Mahle
• ACP78000P — Mahle
• ACP78000S — Mahle
• 6453G5 — Peugeot
• 6453NR — Peugeot
• 98462134 — Peugeot
• 514470100 — PSA
• 6453G5 — PSA
• 6453NR — PSA
• 6453T0 — PSA
• 98462134 — PSA
• E162007 — PSA
• E162212 — PSA
• 090225013 — PSH
• SD7H15-7882 — Sanden
• 7882 — Sanden
• 7908 — Sanden
• SD7H157882 — Sanden
• SD7H157908 — Sanden
• 699028 — Valeo
• 699528 — Valeo
• 813808 — Valeo
• CMP2075 — Wood Auto
• WOOCMP2075 — Wood Auto
